Guangzhou Guangxing Poultry Equipment Group Co., Ltd. one of the leading manufacturers and suppliers of broiler cage spraying system in China. If you're going to buy durable broiler cage spraying system made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.
This 4-in-1 intelligent spray system (high-efficiency cooling, dust suppression, disinfection, humidification) is custom-designed for high-density floor/cage rearing of broilers (1–45 days old), serving as the core environmental control equipment for large-scale broiler farming. Broilers grow rapidly with high metabolism; temperatures above 30°C easily trigger heat stress, leading to sharply reduced feed intake, stunted growth, increased feed-to-meat ratio, higher mortality and severe losses in slaughter weight and profits. Adopting 6–10MPa high-pressure plunger pump atomization technology, the system produces 5–25 micron ultra-fine droplets that evaporate rapidly in the air to absorb heat, cooling the barn by 4–8°C when combined with longitudinal ventilation and effectively alleviating heat stress. The ultra-fine droplets avoid wetting broiler feathers, skin or litter, eliminating cold-induced diarrhea or mold growth. Equipped with temperature-humidity linkage and age-based staged control, the system adapts to the growth needs of 1–10 days (28–32°C, 60–70% RH), 11–25 days (25–28°C, 55–65% RH) and 26–45 days (22–25°C, 50–60% RH). A 3-stage precision filtration system prevents clogging, and the 304 stainless steel body withstands high humidity, heavy dust and strong ammonia corrosion in broiler houses. Suitable for closed and semi-open broiler farms worldwide and compliant with international broiler environmental standards, it provides full-cycle environmental protection for rapid weight gain, reduced feed-to-meat ratio and improved slaughter uniformity of broilers.
Product specifications
|
Parameter Item |
Detailed Specification |
|
Applicable Cage Type |
Stacked/stepped layer cages, fully compatible with all Guangxing Broiler cage series |
|
Working Pressure |
5–10MPa high-pressure atomization, stably outputs ultra-fine droplets |
|
Droplet Size |
5–30 microns, evaporates quickly without wetting broiler feathers or cages |
|
Spray Coverage |
Nozzle spacing 2–3m, coverage ≥90%, no cooling dead zones |
|
Control Mode |
Temp-humidity auto-linkage, timed interval, manual control, remote APP (optional) |
|
Main Unit Material |
304 stainless steel, anti-corrosion and rust-resistant, withstands humid ammonia-rich broiler house environments |
|
Filtration System |
3-stage precision filtration (5μm), backwashable, prevents nozzle clogging long-term |
|
Applicable Temperature |
Cooling ≥30°C; humidification/disinfection suitable year-round |
Product features and advantages
Features
1.Broiler‑specific age‑based staged programs precisely match temp‑humidity needs for 1–10/11–25/26–45 days.
2.High‑pressure mist powerful dust suppression reduces dust by 70%, minimizing broiler respiratory diseases and improving survival rate.
3.304 stainless steel main unit & piping withstand humid, dusty, ammonia‑rich broiler houses, service life ≥5 years.
4.3‑stage precision filtration + ceramic nozzles, no clogging long‑term, maintenance‑free for high‑density farming.
Advantages
1.【Powerful Cooling & Stress Resistance】Rapid 4–8°C cooling eliminates heat stress and sudden death, ensuring stable broiler growth.
2.【Age‑Based Precision Adaptation】Staged temp control for 1–45 days, feed‑to‑meat ratio -0.08~-0.15, slaughter weight +5–8%.
3.【Ultra‑Fine Mist Low Stress】5–25μm droplets avoid wetting feathers/litter, eliminating cold diarrhea, litter mold and coccidiosis.
4.【Dust Removal & Respiratory Protection】70% dust reduction significantly lowers respiratory disease incidence, survival rate +3–5%.
5.【High Harsh‑Environment Resistance】304 stainless steel + ceramic nozzles, 5‑year maintenance‑free in humid ammonia‑rich conditions, long service life.
6.【Intelligent Worry‑Free Operation】Age‑based programs + temp‑humidity linkage, automatic operation, reducing manual duty and errors.
Application scenarios
Hot‑season broiler farms with high heat stress risk use intermittent spray + ventilation for rapid cooling and lower sudden death/mortality.
Packaging and transportation
Packaging: High-pressure spray main unit packed in thickened export cartons with shockproof foam; pipes and nozzles individually wrapped with anti-static pearl cotton; accessories classified and labeled for moisture-proof, shock-proof and anti-corrosion protection of precision parts.
Transportation: Supports FCL/LCL sea freight to major global ports with air freight available for urgency; fumigation certificate, packing list, certificate of origin and certification copies provided; heavy items wooden-framed with full logistics tracking for safe delivery.
FAQ
Q: Will broiler spray wet feathers and cause cold or litter mold?
A: No. 5–25μm ultra‑fine droplets evaporate rapidly in air without contacting feathers or litter, keeping them dry.
Q: Can spray cooling be used in hot and humid weather (＞75% RH)?
A: Not recommended. Spray increases stuffiness at humidity ＞75%; the system stops automatically, prioritizing wet‑curtain + ventilation cooling.
After-sales service
1. Provide bilingual operation‑maintenance manuals and video tutorials specifying daily checks, cleaning cycles and troubleshooting guides.
2.Provide online/on‑site training for operation, programming and linkage debugging for client maintenance personnel before project delivery.
