Guangzhou Guangxing Poultry Equipment Group Co., Ltd. one of the leading manufacturers and suppliers of broiler cage light system in China. If you're going to buy durable broiler cage light system made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.
This intelligent high‑efficiency LED lighting system is custom‑developed for high‑density stacked, H‑type and A‑type broiler cages, suitable for the whole rapid fattening cycle of white‑feathered and yellow‑feathered broilers. Targeting broilers' physiological features of high feed intake, fast growth, high stress sensitivity and frequent pecking behavior, it adopts high‑efficacy, flicker‑free and low‑glare warm‑white light sources. Precision optical design matches cage tier height and internal structure to deliver even illumination without dark areas, reducing chicken huddling and panic. Supporting intelligent timed dimming, circadian rhythm simulation and automatic light‑sensor adjustment, the system can link with ventilation and feeding equipment to scientifically control light duration and intensity. It effectively improves broiler feed intake, feed conversion ratio and slaughter uniformity while lowering feather pecking and mortality risks. With IP66 protection grade, the equipment resists high humidity, dust and ammonia corrosion in chicken houses. Suitable for closed and semi‑open broiler farms worldwide and compliant with international biosecurity standards, it provides a stable, energy‑saving and low‑stress professional lighting solution for large‑scale broiler breeding.
Product specifications
|
Parameter Item |
Detailed Specification |
|
Applicable Cage Type |
Applicable cages: Stacked broiler cages, H-type/A-type broiler cages; fully compatible with all Guangxing broiler cage series |
|
Light Source Type |
High-efficacy LED, flicker-free, low glare, no infrared heat |
|
Power Specification |
5W/8W/12W multiple specifications optional, can be flexibly adapted according to cage layer distance, cage type and breeding density |
|
Light Intensity |
5–50 lux adjustable; early grow-out 8–15 lux, mid–late 20–40 lux |
|
Control Mode |
Three modes: intelligent time control, light sensor linkage and manual dimming, supporting automatic switching of light parameters according to chicken flock day age |
|
Voltage Standard |
AC 220V/380V optional, supporting customization of other voltage specifications, can be directly adapted to power grids of various countries around the world |
|
Protection Level |
IP66(dust/waterproof, resistant to humidity, dust, ammonia) |
|
Color Temperature |
2800–3200K warm white light, highly consistent with the physiological spectrum needs of chicks and young chickens, improving feeding enthusiasm |
|
Service Life |
≥50,000 hours, long-term maintenance-free, with 3-year quality guarantee, reducing operation and maintenance costs |
Product features and advantages
features
Optimized optical simulation for stacked broiler cages with adjusted light angle; no upper‑layer shading, no bottom‑layer shadows, illumination difference within cages ＜15%.
Adopts flicker‑free constant‑current driver to eliminate visual fatigue and panic stress of broilers, reducing huddling behavior.
3000–3500K neutral warm light matches broiler spectral preference, effectively stimulating feed intake and improving feeding uniformity.
Wide‑range dimming from 5–50 lux, precisely adjustable by age; dim light for pecking prevention, bright light for intake promotion.
Supports 24‑hour segmented programming with dim rest‑bright feeding‑gradual transition modes to simulate natural day‑night rhythm.
High luminous efficacy ≥110 lm/W, saving over 65% electricity compared with traditional fluorescent lamps, greatly cutting power costs.
Advantages
1.【Broiler‑Specific Light Formula】Illuminance, color temperature and beam angle customized for rapid broiler growth, significantly improving feed conversion ratio and slaughter uniformity.
2.【Low‑Stress Stable Production】Flicker‑free, low‑glare and gradual‑dimming design reduces panic and pecking, ensuring stable survival rate.
3.【High‑Efficiency Energy Saving】High‑efficacy LED with intelligent timing saves over 65% power vs traditional lighting, greatly cutting long‑term breeding operation costs.
4.【High Resistance to Harsh Environments】IP66 protection and anti‑corrosion materials adapt to dusty, humid and ammonia‑rich broiler houses with long‑term maintenance‑free performance.
5.【Global Voltage Compatibility】Standard 220V/380V with customizable 110V/415V, directly compatible with global power grids without extra transformers.
6.【Easy Installation & Retrofit】Snap‑on quick installation, no rewiring or cage modification for old houses; one house completed in 1-2 days without production interruption.
Application scenarios
Closed broiler houses in hot‑humid Southeast Asia use IP66 lighting systems for stable operation and heat stress reduction.
Packaging and transportation
Packaging:
Each lamp wrapped with anti‑static pearl cotton and packed in 5‑layer export cartons for shock‑proof and moisture‑proof protection; controllers packed in separate cartons with thick foam; cables coiled and labeled; outer cartons marked with packing list, batch number and warning labels.
Transportation:
Supports FCL/LCL sea freight to major global ports; air/land freight available for urgent orders; fumigation certificate, packing list, certificate of origin and certification copies provided; heavy items wooden‑framed with full logistics tracking for safe delivery.
FAQ
Q: What is the main difference between broiler cage lighting and grower cage lighting?
A: Broiler lighting focuses on feed intake promotion, low stress, high efficacy, neutral‑warm color temperature and wide dimming range; grower lighting emphasizes uniform development, pecking prevention and fine age‑based control. Broiler systems feature higher maximum lux, stronger dust resistance and tighter feeding linkage.
Q: Can light flicker cause broiler panic? Are your lamps flicker‑free?
A: Yes, flicker causes panic. Our constant‑current flicker‑free drivers eliminate flicker verified by visual and instrument tests, reducing collision and mortality.
Q: Do lamps fail easily under heavy ammonia and dust?
A: IP66 anti-corrosion flame‑retardant housing resists ammonia, dust and moisture with no obvious aging for 5 years under normal conditions, covered by 3‑year warranty.
After-sales service
1.Provide bilingual operation‑maintenance manuals and video tutorials specifying daily checks, cleaning cycles and troubleshooting guides.
2.Provide online/on‑site training for operation, programming and linkage debugging for client maintenance personnel before project delivery.
